Zanden Aiudio Chouku - new statement mono amp from Zanden Audio
- Thread starter Roysen
- Start date
Looks like a desktop PC, with a big fat valve inside
If I didn't knew it was an amp, I'd think it was a media server/PC!
alexandre
But does it run Windows?
Which tube is that big honker?
Looks like the T1610 , like those used in the KR Audio Kronzilla .
This amp looks a departure from their chrome and gold look ....
I thought the 212 would output 100, 150 W max? It's been a long time so you are probably right, and I may be thinking RF amps/oscillators rather than continuous audio power.
Wonder how long before someone builds an amp using a high-power tube. Water-cooled and all that jazz.
Wonder how long before someone builds an amp using a high-power tube. Water-cooled and all that jazz.
150w max power output usually translates into about 25-30percent rating for single ended audio output. My Wavac's 572b is rated at 160w for radio transmission, but 50w class A single ended for audio, which is probably optimistic.
I would think calling Audio exotics is a good place to start. Or email Eric Pheils at Zanden. If you need details, let me know.
Is an 833 considered a high powered tube? I thought that is the name of the tube in the Wavac 150-watt Class A 833-series amps. I think there is another company which uses that tube as well...Winn?
@cjfrbw: No argument. I am sure the big amps I have dealt with in the primordial past were push-pull and/or something other than class A, especially for radio Tx. I checked the specs (yes, should have done that first) and the WE212 replica is rated 150 W max, 40 W steady-state/DC (which I infer is class A to them).
@lloydelee21: Power designations are another of those things subject to interpretation. One system's high-power tube is another system's driver. The 833 is actually an old radio tube designed primarily for class B or C operation in the modulator or output stage of a medium-power transmitter, say around 150 W for a single tube and perhaps 500+ W for a pair, depending upon the class. As noted above, used for a class A audio circuit, the max output is probably 1/4 that. It is hard to get a good read from the various data sheets I quickly skimmed, but it looks like the two tubes are in generally the same ball-park, with the 833 having a little higher output.
I noticed the Psvane site also listed a much cheaper (~$210) version of the 212 in one of their other series.
Always a hoot seeing the plates glowing cherry-red near full power...
Disclaimer: I do not even know where my old tube manuals are, going off Google for spec sheets...
@lloydelee21: Power designations are another of those things subject to interpretation. One system's high-power tube is another system's driver. The 833 is actually an old radio tube designed primarily for class B or C operation in the modulator or output stage of a medium-power transmitter, say around 150 W for a single tube and perhaps 500+ W for a pair, depending upon the class. As noted above, used for a class A audio circuit, the max output is probably 1/4 that. It is hard to get a good read from the various data sheets I quickly skimmed, but it looks like the two tubes are in generally the same ball-park, with the 833 having a little higher output.
I noticed the Psvane site also listed a much cheaper (~$210) version of the 212 in one of their other series.
Always a hoot seeing the plates glowing cherry-red near full power...
Disclaimer: I do not even know where my old tube manuals are, going off Google for spec sheets...
In holland there was a guy (diy) who designed an amp around the TB3 - 2000 , the 833 is a dwarf compared to that thing.
huge : http://home.tiscali.nl/fishbowl.amping/bouwfase.html
http://forum.zelfbouwaudio.nl/viewtopic.php?f=7&t=12736 scroll down for pics absolutely massive , never heard it unfortunately
There you have some single ended power
huge : http://home.tiscali.nl/fishbowl.amping/bouwfase.html
http://forum.zelfbouwaudio.nl/viewtopic.php?f=7&t=12736 scroll down for pics absolutely massive , never heard it unfortunately
There you have some single ended power
Aretha Franklin - R. E. S. P. E. C. T.
I truly & honestly RESPECT these builders/artists/engineers to an extremely high level.
BUT, I would like to be able to hear these different systems. I would like to hear the music. I would like to know.
Great pics,
zz.
I truly & honestly RESPECT these builders/artists/engineers to an extremely high level.
BUT, I would like to be able to hear these different systems. I would like to hear the music. I would like to know.
Great pics,
zz.
