Dear All,

I am trying to install a VDH colibri XGW on my Triplanar (my existing cart if a Lyra Kleos which is fine). Now when I adjust the overhang, I see that the VDH needs to be set far back in the head shell because the cantilever extends forwards a lot. Anyway - it requires it to be so far back that the back of the cart actually sits on the lip of the arm not flush against the head shell causing this strange angle as below. Furthermore the left part of the cart touches the left part of the arm so I can't alter the orientation of the cart:


Does anyone have experience of Triplanar with VDH colibri and is there a solution? Or am I doing something wrong?


awsmone

Well-Known Member
Apr 7, 2014
1,181
81
48
Canberra Australia
#2
Hi Bill

You have effectively made the tonesrm longer and therefore its arc has changed if the Stylus is beyond tonearm

If you wish to use this cartridge

You can add spacers over the cartridge
Or push the tonarm back on it current mounting position see below...

Please note as per Michael Fremer that the jig is incorrect on original triplanar and you need to go on the measurements as per spec sheet

It's about by about 4 to 5 mm

This might also be your problem?


jfrech

VIP/Donor
Sep 3, 2012
1,586
15
38
Austin
#3
awsmone has a point here. Could it be your tonearm is off on alignment? that said, not all cartridges work on all tonearms.

you could also reach out to triplanar and see if Tri has any knowledge on your arm/table/cart combo.

I've used a Lyra Helicon, Skala and Atlas in a Triplanar. Lyra's make great matches...


TRI MAI
3611 Snelling Avenue
Minneapolis, MN 55406
USA


612-623-0922
tri@triplanar.com

Jun 23, 2015
81
0
6
Brisbane
#4
That just does not look right - cart is no longer than typical
I use the mint lp protractor that is set up with spec dimension as awesome noted and cart sits well forward of headshell
Cheers
Phil


Audiophile Bill

Well-Known Member
Mar 23, 2015
2,477
821
113
UK
#5
Hi Guys,

Thanks so much. I am using the Feickert protractor and actually checked the spindle to pivot distance as per Triplanar site which is 233.5mmm - this seems exactly as per my tt and arm set up, which is a Kuzma pre-drilled arm board. Remember it is fine with my Kleos...


I was also thinking the solution would be spacers - do you guys have any recommendations and will they be deleterious? I am effectively changing the headshell weight I guess?

I contacted Triplanar - received an email this morning from Tri saying to call him.

Best,

Bill


Audiophile Bill

Well-Known Member
Mar 23, 2015
2,477
821
113
UK
#6
That just does not look right - cart is no longer than typical
I use the mint lp protractor that is set up with spec dimension as awesome noted and cart sits well forward of headshell
Cheers
Phil
Hi,

This Colibri is a good deal longer than my Lyra - much longer in fact. It isn't the body so much but the protruding nature of the cantilever really adds to it.


Audiophile Bill

Well-Known Member
Mar 23, 2015
2,477
821
113
UK
#7
awsmone has a point here. Could it be your tonearm is off on alignment? that said, not all cartridges work on all tonearms.

you could also reach out to triplanar and see if Tri has any knowledge on your arm/table/cart combo.

I've used a Lyra Helicon, Skala and Atlas in a Triplanar. Lyra's make great matches...


TRI MAI
3611 Snelling Avenue
Minneapolis, MN 55406
USA


612-623-0922
tri@triplanar.com
Yeah my first plan was to upgrade my Kleos to an Etna but the price of this Colibri is extremely attractive - exceptional used deal.


gian60

Well-Known Member
Apr 17, 2016
1,727
500
113
#8
I also have a Colibri but cannot use with my Bergmann Sindre because cannot set far back like needed,and i sold


Audiophile Bill

Well-Known Member
Mar 23, 2015
2,477
821
113
UK
#9
I can't use spacers either actually because the rear of the cart hits arm tube and would need like 0.75cm spacer:


As you can see I can't adjust the orientation according to the parallel lines at the null points because I can't rotate it...


awsmone

Well-Known Member
Apr 7, 2014
1,181
81
48
Canberra Australia
#10
You can change the effective length two ways

One is to use smaller bodied mounting screws which will give you about 4 mm of wiggle room

The other is to take the triplanar off

And underneath is a mounting screw that holds the base to the pillar for vta

This is very tight, but loosening it allows you to push back the pivot point to accommodate this cartridge

I think this might void the warranty so you need to check with Mai

This will then allow you to mount the cartridge

Good luck


Audiophile Bill

Well-Known Member
Mar 23, 2015
2,477
821
113
UK
#11
You can change the effective length two ways

One is to use smaller bodied mounting screws which will give you about 4 mm of wiggle room

The other is to take the triplanar off

And underneath is a mounting screw that holds the base to the pillar for vta

This is very tight, but loosening it allows you to push back the pivot point to accommodate this cartridge

I think this might void the warranty so you need to check with Mai

This will then allow you to mount the cartridge

Good luck
Thanks so much Awsmone. I think that the solution of removing the arm and loosening it to bring back the pivot point might work.


tima

Industry Expert
Mar 4, 2014
922
459
63
#13
Coming back to this thread. Bill did you ever resolve the issue with your Triplanar and the VDH colibri XGW?


Audiophile Bill

Well-Known Member
Mar 23, 2015
2,477
821
113
UK
#15
Coming back to this thread. Bill did you ever resolve the issue with your Triplanar and the VDH colibri XGW?
Hi Tima,

Only insofar as I ended up altering the effective length and geometry with the tweak as per above but it resulted in not a good sound - too much sibilance for me.

Likes: tima

tima

Industry Expert
Mar 4, 2014
922
459
63
#17
Hi Tima,

Only insofar as I ended up altering the effective length and geometry with the tweak as per above but it resulted in not a good sound - too much sibilance for me.
Thanks for the follow-up. I had a similar situration and similar results. My solution was to use the vdH with a different toneam (4Point). The cart was still fairly far back on the headshell. I hear what I can best describe as the possibility of sibalance, but nothing overt, yet. Still have quite a bit of break-in.


Audiophile Bill

Well-Known Member
Mar 23, 2015
2,477
821
113
UK
#18
Thanks for the follow-up. I had a similar situration and similar results. My solution was to use the vdH with a different toneam (4Point). The cart was still fairly far back on the headshell. I hear what I can best describe as the possibility of sibalance, but nothing overt, yet. Still have quite a bit of break-in.
I spent ages trying to make it work. I must have spent a 2 weeks altering ever parameter to improve things (Triplanar very good for this) to no avail.

May 4, 2013
65
36
18
#19
The colibri was terrible so inconsistent no two were the same, the right one was capable of great results. I had to always specify it to be used with the Triplanar, at one time I purchased 50 vdh cartridges at one go and many of them were useless still have quite a few sitting around.
